One-step Silane Crosslink Extrusion Line

Application:

The one-step Silicohydride Crosslink Insulation Extrusion Line is designed for the insulation extrusion of cooper and aluminum conductors. It is suitable in the insulation extrusion for power cables range from 1kV to 10kV, also suitable for overhead conductors, plastic cables and etc. Applicable materials include PVC, PE and XLPE.

Technical Parameters:

Voltage	1KV-10KV Crosslinking cable
Voltage	1KV-10KV Crosslinking aerialline
Conductor Material	Aluminum, Copper
Conductor Material	Up to IEC 228 Standard
Corss Sectional Area of Conductor	10-630mm2
Conductor Diameter	4.0-40.0mm
Cable Diameter	9.5-42.0mm
Weight of Cable	Max. 7.0kg/m
Wall thickness	Inner shied:0.4-0.8mm
	Insulation: 0.8-3.5mm
	Color Skin: 0.1-0.5mm
	Line Speed Max. 80m/min
Capacity of Extrude 65/25D	PE: Max. 120kg/h
120/30D	PE:Max.450kg/h
Middle Voltage Cable
Inner Shied Material	Semi-conductive PE(Borealis), SIOPLAS(AEI)
Insulation Material	PE,2100TN00,218W, 18D..
Liquid Silane	SILIX, SILMIX316,301
Liquid Silane	Carbon black master batch: silix-c401
Low Voltage Cable
Insulation Material	PE, 2100TN00,218W, 18D...
Liquid Silane	SILIX, SILMIX316,301
Liquid Silane	Carbon black master batch: SILIX-C401
Color Skin	PE,PVC or SIOPLAS (AEI), Color Masterbatch

Extrusion Funtion:
